额定载荷Rated Load |
2t-60t |
|
额定输出Rated Output |
2.0000±0.001MV/V |
|
综合误差Total Error |
±0.02%F.S |
|
蠕变Creep(30minutes) |
±0.02%F.S |
|
推荐工作电压Recommended Excitation Voltage |
5V～18V(DC) |
|
最大工作电压Maximum Excitation Voltage |
24V(DC) |
|
零点平衡Zero Balance |
±1%F.S |
|
输入阻抗Input Impedance |
775±5Ω |
|
输出阻抗Output Impedance |
700±2Ω |
|
绝缘阻抗Insulation Impedance |
≥5000MΩ |
|
安全过载率Safe Overload |
150%F.S |
|
极限过载率Ultimate Overload |
200%F.S |
|
工作温度范围Operating Temperature Range |
(-30～+70)℃ |
|
温度补偿范围Compensated Temperature Range |
(-20～+60)℃ |
|
输出温度影响Temperature Effect On Load |
±0.02%F.S/10℃ |
|
零点温度影响Temperature Effect On Zero |
±0.02%F.S/10℃ |
|
材质Construction |
合金钢Alloy Steel 铝合金Aluminium |
|
防护等级Protection Class |
IP68&IP67 |
|
引用标准Citation |
GB/T7551-2008/OIML R60 |
|
接线方式Mode of Connection |
输入+:红 Input+:Red
输入-:黑 Input-:Black
输出+:绿 Output+:Green
输出-:白 Output-:White |
